GenCell EVOX® Grid-Optional Hydrogen Fuel Cell EV Charging & BESS System

Asset Location: United States (Containerized for immediate rapid deployment)

Bidding Type: Online Webcast Auction

Status: Certified Components & Top-Tier Engineering

Lot Description & Auction Overview

Asset Built is proud to present a premier industrial asset open for public bidding: a GenCell EVOX® Hydrogen-Fueled EV Charging and Grid Enhancement System.

Engineered to completely bypass utility capacity limits and grid upgrade bottlenecking, this high-value EVOX® unit represents a major advancement in distributed power generation and energy storage. This self-contained, containerized system integrates a premium zero-emission fuel cell infrastructure with a high-capacity Battery Energy Storage System (BESS), managed on-site via advanced energy resource software.

Ideal for commercial EV fleet operations, field-deployed industrial operations, or site-wide mission-critical backup power, this modern asset allows the winning bidder to deploy immediate fast-charging capabilities without the typical multi-year grid infrastructure delays.

Core Specifications & Performance Metrics

• Daily Energy Generation Capacity: Engineered to deliver up to 1,680 kWh per day.

• Integrated Battery Storage (BESS): CATL EnerOne 1C Liquid-Cooled 372.5 kWh Battery Subsystem featuring highly stable Lithium Iron Phosphate (LFP) chemistry.

• Rated Output Parameters: 375kW Rated Output Power, delivering 277/480VAC 3-Phase power at a 0.95 power factor.

• Fast Charging Support: Designed to service multiple Level 2 and Level 3 DC Fast Chargers (50–350kW), enabling transport vehicles to reach an 80% charge within 12 to 30 minutes entirely off-grid.

• Grid-Optional Inputs: Features configurations to operate 100% independent of the local grid, with existing connections for standard utility integration (480V/208V 3-Phase) or supplementary renewable assets like solar arrays.

Heavy Industrial Componentry & BOM Highlights

This asset consists of a sophisticated multi-source power build utilizing top-tier componentry from premier manufacturers:

1. Power Conversion & Battery Subsystems

• Battery Module: 1x CATL EnerOne 373 kWh LFP liquid-cooled outdoor enclosure.

• Inverters / PCS: 3x Dynapower MPS-125-100 Power Conversion Systems (Combined 375kW capacity).

• DC/DC Isolation: 2x Epic Power EPC 5K5 648i Isolated Bi-Directional DC/DC converters.

• Fuel Cell Infrastructure: Dual GenCell generation boxes utilizing advanced hydrogen-to-power technologies.

2. Electrical Protection, Switching & Telemetry

• Molded Case Circuit Breakers: Premium ABB Tmax series safety protection line, including an ABB 380A Breaker (XT5N), 600A Breakers (XT5S), and multiple 200A Breakers (XT3N) for secure distribution routing.

• Transfer Switches: ABB TruONE Automatic and Manual Transfer Switches.

• Telemetry & Metering: Acrel ADL3000-E-B/KC three-phase multi-function power meters for granular load monitoring.

• Surge Protection: Heavy-duty Zenyau ZYSPD25T385B4 surge suppression units matched for battery energy storage protection.

3. Control, Automation & Safety Enclosures

• Industrial Computing: Advantech ARK-1221 IoT Edge Microcontroller paired with Advantech EKI-1224I Modbus Gateways and unmanaged industrial switches for zero-latency telemetry.

• Relay Systems: ABB pluggable interface relays (CR-MX series) throughout the automation line.

• Safety Interlocks: Onboard hydrogen leak detection and emergency shutoff system integrated alongside an independent localized fire/smoke suppression array within the BESS container.

• Environmental Regulators: High-efficiency Kacon space heaters/controllers paired with an array of 15 Blauberg BL-A250C-EC-00S clean-running industrial ventilation fans to assure continuous air exchange and cooling.

Mechanical & Physical Footprint

The entire system is securely housed within a standardized intermodal shipping container optimized for swift rigging and transit:

• Form Factor: 20' HC ISO Shipping Container

• Dimensions: 19.9 ft (L) x 8.0 ft (W) x 9.5 ft (H)

• Total Weight: 28,000 lbs

• Regulatory Compliance: Batteries and structural enclosure are fully UL9540 and UN3536 certified.

Onboard Intelligent Management Platform

The system includes a fully integrated deployment of the GenCell GEMS™ Energy Management Software Platform. Managed via a native edge interface (GEMS™ Edge embedded microcontroller), this software optimizes operations by:

1. Dynamically prioritizing power resources based on real-time cost-efficiency metrics.

1. Balancing fuel cell generation alongside auxiliary grid or solar PV inputs.

1. Direct data integration tracking for commercial third-party EV charging payment mobile applications.

1. Real-time hydrogen level calculations and remote web-based system monitoring.

Bidding Information & Auction Terms

• Inspection: Available by appointment only. Please contact the auctioneer to schedule a physical or virtual site preview.
• Removal & Load-out: Containerized design allows for simplified freight logistics. Winning bidder is responsible for all rigging, logistics, and transportation costs.

• Terms: Subject to standard auctioneer terms and buyer’s premium. Review the full catalog details, technical documents, and payment wiring instructions prior to bidding.
